Mini wheel loader H130 is latest developed, more compact in construction, lighter in the model and therefore more suitable family farm work and garden working as well as narrow place.
Engine | ZONSEN DOUBLE Cylinder |
Emission Standards | Stage V and EPA |
Net power | 16.8kW@3600rpm |
Fuel | Gasoline |
Transmission | Hydrostatic |
Drive speed (max) | 12km/h(7.5 mph) |
Aux. hydraulic oil flow | 19L/min (5 GPM) |
Max lifting height | 1.8m(70.9in) |
Breakout force / 50 cm(19.7 in) | 250Kg (551lbs) |
Turning radius: inside/outside | 0/993mm(0/93 in ) |
Tyre Size | 18x8.50-8 |
Weight | 398Kg (880 lbs) |
Tipping load (w/back weights) | 320Kg (705 lbs) |
Lifting capacity (w/back weights) | 250Kg (551lbs) |
1200kg
4408x1160x2510mm
18.4KW/25HP
500kg
3100*1150*2100
750AH/60V
400kg
900 AH 60 V
900KG
600kg
300AH 48V
1930kg
800-1000kg
960AH 96V
3200kg
1500-2000kg
42/55 KW
4400kg
5000kg
200 KW/H
4x4WD
