This mini wheel loader is a versatile mechanical device with a telescopic arm design that allows it to work in tight spaces or under obstacles. It is suitable for a variety of industrial and construction applications, such as transporting, loading and unloading cargo and other tasks, with high efficiency, safety and flexibility, and adopts an energy-saving and environmentally friendly design.
Technical data | H280T | |
Engine model | YANMAR 4TNV88-BIGE | Kubota V2403-M-DI-E3B-CSL1T |
Fuel type | Diesel | |
Cylinders | 4 | |
Displacement (cc) | 2190 | 2434 |
Emission standards | EU Stage V | China Off-Road GB4 |
Max engine output (KW) | 18.5@1500rpm | 36.5@2600 rpm |
Max engine torque (Nm) | 141@1500rpm | 158.6@1600rpm |
Cooling system | Water | |
Operating voltage (V) | 12 | |
Battery (Ah) | 75 | |
Operating weight (kg) | 3500 | |
Tipping load ,max (kg) | 1700 | |
Lifting capacity,max (kg) | 1500 | |
Operator's cab | Cabin | |
Travel speed (km/h) | 0~25 | |
Steering angle (°) | 45 | |
Turn radius inside/outside (mm) | 1270/3270 | |
Standard tires | 10.0/75-15.3 | |
Fuel tank capacity (L) | 40 | |
Hydraulic oil tank capacity (L) | 50 | |
Working hydraulic flow (l/min) | 60 | |
Working hydraulic pressure (bar) | 200 | |
Transmission type | Hydrostatic | |
