• Hydraulic joystick control, operate more flexible
• Enlarged enclosed cabin with A/C
• The strong boom,bucket and bucket teeth, improve the working range
• The strong robot-welded structure,ensures the excellent durability
• Strengthened chassis, forging articulated parts,by changing material shape and thickness to relieve stress,improved durability
• The machine can be used for earthwork excavation,loading,leveling, Slope protection,crushing,dismantle, trenching, also be used for mining and worst working conditions.
性能参数 Specifications | ||
机器重量(KG) | Weight | 16000 |
挖斗容量(m³) | Bucket Capacity | 0.8-1 |
回转速度(rmp) | Swing Speed | 12 |
最大爬坡角度(°) | Gradeablity | 25 |
挖斗最大挖掘力(KN) | Max.Bucket Digging Force | 100 |
斗杆最大挖掘力(KN) | Max.Arm Digging Force | 70 |
发动机 | Engine | Cummins |
发动机型号 | Engine Model | B5.9CS4-150C |
功率/转速(KW/rmp) | Power/revolution speed | 110/2200 |
轮胎型号 | Tire Model | 10.00-20 |
系统压力(MPa) | System Pressure | 32 |
行驶速度(km/h) | Traveling Speed | 35 |
柴油箱(L) | Diesel tank | 220 |
液压油箱(L) | hydraulic oil tank | 200 |
液压马达 | Hydralic motor | Heavy duty HM6V115 |
整机尺寸 Machine size | ||
外形尺寸长x宽x高(mm) | Dimension Length*Width*Height | 8050*2595*3255 |
驾驶室高(mm) | Cabin Height | 3150 |
轴距(mm) | wheel base | 2600 |
轮(轨)距(mm) | tread | 1955 |
最小离地间隙(mm) | Minimum ground clearance | 430 |
尾部回转半径(mm) | Tail Swing Radius | 2365 |
作业范围 Working range | ||
最大挖掘高度(mm) | Max.Digging Height | 8800 |
最大卸载高度(mm) | Max.Dumping Height | 6310 |
最大挖掘深度(mm) | Max.Digging Depth | 5350 |
最大垂直挖深(mm) | Max.Vertical Digging Depth | 4685 |
最大挖掘半径(mm) | Max.Digging Radius | 8363 |
最小回转半径(mm) | Min.Swing Radius | 2723 |
推土铲最大离地间隙(mm) | Max.Dozer Blade Lifting Distance | 420 |
推土板沉下最大深度(mm) | Max.Dozer Blade Cutting Distance | 85 |
