操作重量 Operating weight

Kg

8500

铲斗容量Bucket capacity

m³

0.28

发动机 Engine

发动机型号Model

/

Weichai

电喷或直喷？Electronic Injection or Direct Injection?

/

Electronic Fuel Injection

冲程Four strokes

/

4

水冷 Water cooling

/

Water

涡轮增压Turbo-charging

/

\

空空中冷Air to air intercooler

/

\

缸数 No. of cylinders

/

4

额定功率/转速 Rated power/speed

kw/rpm

48/2200

最大扭矩/转速 Maximum torque/speed

N.m

260/1600

排量 Displacement

L

2.982

主要性能
Main performance

回转速度 Swing speed

r/min

11

爬坡能力Grade-ability

%

35

最大牵引力 Maximum tractive force

kN

86

液压系统
Hydraulic system

主泵品牌型号Main pump

/

Zhongrun Hydraulics

主泵额定流量Rated flow of main pump

L/min

176

主安全阀压力Main safety valve pressure

MPa

28

底盘

Undercarriage

最高行驶速度

km/h

33

油类容量
Oil Capacity

燃油箱容量Fuel tank capacity

L

165

液压油箱容量Hydraulic tank capacity

L

110

发动机油容量Engine oil capacity

L

8

冷却液Coolant

L

18

行走马达Final drive

L

4

外形尺寸
Appearance size

A 总长 Overall length

mm

6620

B 总宽 Overall width

mm

2172

C 总高(动臂顶) Overall height(Boom top)

mm

2765

D 总高(驾驶顶) Overall height(cab top)

mm

2773

E 配重离地间隙Counterweight clearance

mm

1055

F最低离地间隙Min.ground clearance

mm

239

G尾部回转半径Min.tail swing radius

mm

1787

H轴距

mm

2400

I轮距

mm

1668

N 转台宽度Turn-able width

mm

2045

作业范围
Working scope

O最大挖掘高度Max.digging height

mm

7274

P 最大卸载高度Max.dumping height

mm

5450

Q 最大挖掘深度Max.digging depth

mm

3645

R 最大垂直挖掘深度Max.vertical wall digging depth

mm

2606

S 最大挖掘深度 Max.digging depth for

mm

2500

T最大挖掘距离Max.digging reach

mm

6486

U在地面的最大挖掘距离Max.digging reach at ground level

mm

6029

V 最小回转半径Min.swing radius

mm

2045

W 最小回转半径时最大高度Min.height at min.swing radius

mm

5886

Z 配重高度Counterweight height

mm

2022

A1 接地长度(运输时)Ground length(Transportation)

mm

3725

动臂长度Length of boom

mm

3725

斗杆长度Length of arm

mm

1620

铲斗斗容Bucket capacity

m³

0.28
